Back Orthopaedic Case · 01

Ilial wing fracture

Pelvic stabilisation in a young domestic shorthair after polytrauma.

PatientCharlie
Patient detailsDomestic Shorthair · 2 years · Female
ProcedurePelvic fracture repair
Content advisory: This page contains explicit clinical imagery (anatomical structures, surgical procedures or X-rays) intended for veterinary professionals.

This sweet cat was brought in by a member of the public after being seen dragging her back legs. A charity centre kindly took on her case and supported her recovery, allowing us to help with her fractured hip.

Presentation & imaging

On presentation, Charlie was unable to bear weight on her pelvic limbs. Withdrawal reflex and nociception were present, with normal proprioception in the right pelvic limb but delayed in the left.

Radiographs confirmed:

  • Right sacroiliac luxation
  • Left oblique ilium body fracture
  • Left ischium fracture involving the acetabulum
  • Bilateral pubic fractures
Pre-op pelvis
Fig. 1 — Pre-op pelvis
Pre-op pelvis lat view
Fig. 2 — Pre-op pelvis (lat view)

Surgical plan & repair

To address her injuries, a 2.4 mm screw was placed to stabilise the sacroiliac joint, and a 2 mm SOP plate with two proximal and two distal screws was used to reduce the ilial fracture.

Post-op stabilisation
Fig. 3 — Post-op stabilisation
Post-op lat view
Fig. 4 — Post-op (lat view)

Outcome

Charlie made an excellent recovery and was using all four limbs during follow-up checks. An FHNE may be necessary in the future if the acetabular fracture leads to discomfort.
